  #16
Old 11-04-2010, 04:25 AM
mikesturbo94 mikesturbo94 is offline
No foolin it was spoolin

Join Date: Mar 2010
Posts: 1,383
Send a message via MSN to mikesturbo94
Default Re: 94 with 01+ bumper

1. Get all the 01+ brackets mount them to the bumper
2. take the two 94 L shaped brackets that bolt to the frame and have the top hole that bolts to the bumper extended to the width of the bracket and have a slot made in the middle where the crease is in the metal, but you have to switch sides of the brackets left goes on the right and the right on the left and then space them out about 3/4" to and 1" from the frame rails (can't use stock bolt thing) have to get longer bolts and I used washers as a spacer. the reason for this is the distance between the mounting holes on the 01+ bumper is greater then that of the 94, so when you swap the sides of the brackets and space them that gives you the adjust ment you need to line everything up.
3. That's what I did but after install I realized I could have done it this way: swap the bracket sides mount and space them from the frame, tighten down then measure the distance between the mounting holes on the 01 bumper, go back to the brackets on the truck and drill a hole in the middle of each bracket that distance apart and them bolt the bumper to them and line it up should be centered if measured right you just need to adjust the height and tighten down. Next remove the entire setup from the frame leaving the 94 brackets bolted to the bumper once removed you can drill the new top hole for each side and bolt that together and reinstall on the truck and you should be good to go.

I hope that explains it well enough and you get the idea, it's 4am and I just woke up for no reason so I figured Id check FRF out lol, I should have took pic during the install but i was to excited to get it on that I totaly forgot to, oh well hope that works for you, when I wake up again I'll re read this post and edit it if I have to lol. And on that bombshell goodnight
__________________
2008 ford escape xlt 3.0 v6 4x4

94 xlt 5spd longbed,
Was a built 2.3 turbo currently no motor or trans
5.0 swap coming soon
6/5 drop with dream beams,8.8 373 posi,17x9 wheels,swp seats,8k hids, autometer guages, Wideband o2, shiftlight, illusive trans x-member, 01-04 4x4 front bumper
PNW Crew
AC
Reply With Quote
  #17
Old 11-04-2010, 08:41 AM
Bwad Bwad is offline
Turd Generation Ranger

Join Date: Jan 2010
Posts: 2,972
Default Re: 94 with 01+ bumper

Thanks a bunch, Mike! I am really excited to get this done!
__________________
1997 Ford Ranger 2.3L
It's lowered and stuff.

My Build Thread
Reply With Quote
  #18
Old 11-05-2010, 07:36 PM
mikesturbo94 mikesturbo94 is offline
No foolin it was spoolin

Join Date: Mar 2010
Posts: 1,383
Send a message via MSN to mikesturbo94
Default Re: 94 with 01+ bumper

I know this is my bumper thread but with my bumper update I also ordered this Illusive design & frabrication low profile transmission crossmember I will be installing middle of next week on my 4 days off, I will also be putting my foglights in tomorrow and I'll take pics of them installed and post them
__________________
2008 ford escape xlt 3.0 v6 4x4

94 xlt 5spd longbed,
Was a built 2.3 turbo currently no motor or trans
5.0 swap coming soon
6/5 drop with dream beams,8.8 373 posi,17x9 wheels,swp seats,8k hids, autometer guages, Wideband o2, shiftlight, illusive trans x-member, 01-04 4x4 front bumper
PNW Crew
AC
Reply With Quote
  #19
Old 11-06-2010, 03:59 PM
mikesturbo94 mikesturbo94 is offline
No foolin it was spoolin

Join Date: Mar 2010
Posts: 1,383
Send a message via MSN to mikesturbo94
Default Re: 94 with 01+ bumper

Installed the trans x member today had alil time before work

Eh alil bit of difference


stock one where I hit a peice of rebar the was sticking up in a parking lot

__________________
2008 ford escape xlt 3.0 v6 4x4

94 xlt 5spd longbed,
Was a built 2.3 turbo currently no motor or trans
5.0 swap coming soon
6/5 drop with dream beams,8.8 373 posi,17x9 wheels,swp seats,8k hids, autometer guages, Wideband o2, shiftlight, illusive trans x-member, 01-04 4x4 front bumper
PNW Crew
AC
Reply With Quote
  #20
Old 11-09-2010, 04:16 PM
mikesturbo94 mikesturbo94 is offline
No foolin it was spoolin

Join Date: Mar 2010
Posts: 1,383
Send a message via MSN to mikesturbo94
Default Re: 94 with 01+ bumper

Foglights are in woo

they are wired to the corner markers

__________________
2008 ford escape xlt 3.0 v6 4x4

94 xlt 5spd longbed,
Was a built 2.3 turbo currently no motor or trans
5.0 swap coming soon
6/5 drop with dream beams,8.8 373 posi,17x9 wheels,swp seats,8k hids, autometer guages, Wideband o2, shiftlight, illusive trans x-member, 01-04 4x4 front bumper
PNW Crew
AC
Reply With Quote
  #21
Old 11-09-2010, 04:21 PM
Sandman Sandman is offline
I'm ya Huckleberry!!!

Join Date: Nov 2009
Posts: 259
Default Re: 94 with 01+ bumper

nice looks good
__________________
1998 Project Black Stallion
4.0 built by me with .030 pistons comp cam head and intake work. 3" BL explorer rear spring and a t-bar crank comp x-alloys on 33" BFG AT TA KO's

1987 Project Blackfoot
2.3 soon to be turboed with a 4/5 drop and 18's not sure which ones yet and a complete redo of the interior
Reply With Quote
  #22
Old 11-09-2010, 08:29 PM
Bwad Bwad is offline
Turd Generation Ranger

Join Date: Jan 2010
Posts: 2,972
Default Re: 94 with 01+ bumper

Nice, Mike! You gonna go HID for your fogs too?
__________________
1997 Ford Ranger 2.3L
It's lowered and stuff.

My Build Thread
Reply With Quote
  #23
Old 11-09-2010, 08:50 PM
kulon00ranger kulon00ranger is offline
Learning to use the forums

Join Date: Nov 2010
Posts: 10
Default Re: 94 with 01+ bumper

that looks tough! i want to upgrade my 00 font end to look like an 01 or newer
Reply With Quote
  #24
Old 11-09-2010, 08:55 PM
dixie_boysles dixie_boysles is offline
5.Oh All the way


Join Date: May 2009
Posts: 6,581
Send a message via Yahoo to dixie_boysles
Default Re: 94 with 01+ bumper

man that thing is hideous, send it my way
__________________
2014 F150 SuperCrew XLT 4x4
275/65/17 Falken Wildpeak AT3W | Shorty Antenna | Tinted Windows | ProClip Phone Mount |5.0 v8 |Tow Package | Oxford White


Sold/Totaled: 2006 Ranger XLT 2D SuperCap 4x4 Torch Red
15x8 Pacer 164P Polished Wheels | 31x10.50 BFG ATs | Level II Tow Hooks | FX4 Red Insert Seats
Tinted Windows | 6000K HIDs | Kobalt Low Profile Toolbox | Pioneer Speakers
Reply With Quote
  #25
Old 11-10-2010, 05:07 PM
RangeRansom RangeRansom is offline
SaleenStormTrooper

Join Date: Jul 2010
Posts: 259
Default Re: 94 with 01+ bumper

looks good doggie, nice work, i like the black and chrome look you got going on.

DAN CRYMES- i will send you clips and bolts, so you can put that ish on already, i dont know why you dont just order them.. you work at advanced auto for crise-sakes
__________________
Rangers of Texas
Reply With Quote
  #26
Old 11-10-2010, 05:18 PM
Casper Casper is offline
Adam's > Everything else

Join Date: Dec 2009
Posts: 1,636
Default Re: 94 with 01+ bumper

looks good mang! now get some 3k's for them!
__________________
98 Ranger some stuff done

PNW Crew
Reply With Quote
  #27
Old 11-10-2010, 05:25 PM
mikesturbo94 mikesturbo94 is offline
No foolin it was spoolin

Join Date: Mar 2010
Posts: 1,383
Send a message via MSN to mikesturbo94
Default Re: 94 with 01+ bumper

Yes I'm putting hids in the fogs going to be matching my headlights, and I didn't get clips either I went to the hardware store and bought six nuts and bolts for the fogs works perfect and cost me all of a 1.15 to put them in

----------

Quote:
Originally Posted by Casper View Post
looks good mang! now get some 3k's for them!
yea yea Billy, is 3k yellow? And what u have 9005?
__________________
2008 ford escape xlt 3.0 v6 4x4

94 xlt 5spd longbed,
Was a built 2.3 turbo currently no motor or trans
5.0 swap coming soon
6/5 drop with dream beams,8.8 373 posi,17x9 wheels,swp seats,8k hids, autometer guages, Wideband o2, shiftlight, illusive trans x-member, 01-04 4x4 front bumper
PNW Crew
AC
Reply With Quote
