Default 2004-2008 Engine bay pictures

Hey guys,

I haven't seen many pictures of engine bays on here. I really need to see some becuase I'm getting ready to pull my 3.0 OHV and put a 4.0 SOHC in it's place. I need to know all the parts that I'll need to get from the 2008 Ranger with the 4.0. I'm going to post a pic of my 3.0 and a pic of the 4.0 SOHC. Take a close look at the firewall where the wiring harness plugs in. I only have one big plug and the 4.0 has 3 smaller plugs.

My 2004 3.0

The 2008 4.0


Last edited by Fordfan444; 08-15-2010 at 08:27 PM.
Reply With Quote
  #2
Old 09-15-2010, 02:34 PM
4evermodding 4evermodding is offline
Modding To Continue >>>>

Join Date: May 2009
Posts: 1,114
Default Re: 2004-2008 Engine bay pictures

go to the JY and take many pics, it will be much better
__________________
http://s694.photobucket.com/user/dix...dding.jpg.html

They will remember me always
Reply With Quote
  #3
Old 09-15-2010, 03:59 PM
TurdFX4 TurdFX4 is offline
Sept. 2011 TOTM

Join Date: Jan 2010
Posts: 1,771
Default Re: 2004-2008 Engine bay pictures

Reply With Quote
