Default tbar crank pics!!!

hey it would be great if you could put PICTURES here of your torsion bar crank. and also list the negatives to doing it... if there are any.
want to see how it looks.
THANKS
__________________
2003 FX4 Off Road- 4.0L V6
fav. mod- cab clearance lights

-torsion bars maxed-
Reply With Quote
  #2
Old 03-03-2010, 07:21 PM
carfinatic24 carfinatic24 is offline
Liking the Ford Ranger Forum

Join Date: Mar 2010
Posts: 17
Default

you just put strain on your cv axles doin that. i have mine all the way turned up and everything seems fine though
__________________
ranger with 33X12.50 all terrains with torsion bars turned up all the way and a 3" block in the back, intake, and flowmaster 50 series with duals.
Reply With Quote
  #3
Old 03-03-2010, 07:26 PM
Ranger_EDGE Ranger_EDGE is offline
SVT

Join Date: Sep 2009
Posts: 2,522
Default

ok i didn't max them out because i didn't want them to wear faster so i just did it enough to bring the front up to try and level it out but yea it really didn't work unless i max them out. but here are some pics of before and after

before-


after t-bar crank-



i love it a lot better then the way it was.
__________________
-1995 ford ranger prerunner, 4.0, 4x4, 5-speed, 62k original miles, 2.5 radflo bypass front and 2.5 radflo triple bypass rear, deavers f23, 4.56 gears front and back, 07 seats, 07 mirrors, 35x12.50 bfg a/t, 4" fiberwerk glass front and rear, eagle alloy rims, 6k hid heads, two 8k hid off road lights, 34" led light bar, bed/roll cage/engine cage, 25 gallon fuel cell, cut and extended beams/radius arms
-2000 ford SVT f150 lightning -SOLD Lifted 2001 Ford Ranger EDGE, April's 2012 TOTM
Reply With Quote
  #4
Old 03-03-2010, 07:53 PM
STL STL is offline
...............


Join Date: May 2009
Posts: 23,398
Default

Only picture I have was when I got the 31's

I did the t-bar crank then drove up to get my new tires.

__________________
2005 Edge

Reply With Quote
  #5
Old 03-03-2010, 08:45 PM
Areyouforcereal? Areyouforcereal? is offline
Touch it.

Join Date: Jan 2010
Posts: 809
Default

The neg. is that it will wear out your t-bars faster, and the suspension will start to sag sooner. I cranked mine about 3 years ago, and after heavy use they are sagging and back to the stock ride height.
__________________
2003 Ranger FX4 level II. 3" BL, 33x12.50 GT Radial Mud Claws, Custom front and rear bumpers with winch hookups, custom flatbed, with hi-lift, and full size spare mount, 12,000 lb winch mounted under bed, Electric fan, and of course a flowmaster.
Reply With Quote
  #6
Old 03-04-2010, 01:07 AM
Tom Tom is offline
Ranger Enthusiast

Join Date: Nov 2008
Posts: 6,829
Default

My truck has a t-bar crank, check the avatar.
__________________
2006 Ford Ranger Sport 4.0 2WD on 32x11.50R15s
-3" Doetsch Spindle Lift


Using the forum:
How to Post on the Forum
Creating a signature (do this before asking any questions)
Upload an Avatar (image of your Ranger)
How to Post Pictures on the Forum
Switch the site layout: Light Theme or Dark Theme

Things to do:
Participate in Truck of the Month
Participate in the Ranger Photo Contest
Participate in the Non-Automotive Photo Contest
Become a Site Contributor
Shop at the FordRangerForum.com Store
Reply With Quote
  #7
Old 03-04-2010, 01:22 AM
Smokey Smokey is offline
Senior Member

Join Date: Jan 2010
Posts: 597
Default

Quote:
Originally Posted by Tom View Post
My truck has a t-bar crank, check the avatar.
You need to upload pics of your truck to an album buddy. just like everyone else.
__________________
1999 3.0 XLT 2WD
3" Performance Accessories Body Lift| 3" Susp. Lift (Coil Spacers w/Blocks in the rear)| 33x12.50 Big Foot X/T's| 70's Style Blade Wheels| Pro Comp ES 3000 Shocks| Fabbed front bumper w/ 4 130W KC Daylighters| Black grille| Cherry Bomb Glass Packs| Fabbed rear bumper w/ detachable tire mount| Stock 3.73 gears.....for now| Auto Trans.

Reply With Quote
  #8
Old 03-04-2010, 05:02 PM
mcpink mcpink is offline
Infidel

Join Date: Nov 2009
Posts: 1,771
Default

I just leveled mine out a bit, maybe four turns each side to get about 2.5 inches. Threw my camber out a bit, but otherwise I like the ride (it's a little more stiff, but not bad at all)

Prior to the crank:


After:
__________________
02 Ranger XLT 4x4 Off Road, 4.0L SOHC, Automatic, 8.8 4.10 LS, Super-Cab, 3" Body Lift, 33x12.5x15 BFG All Terrains on 15x8 M/T Classic IIs, 5K 55w Heads, 5K 35w fogs, custom front skid plate, various other goodies.
Reply With Quote
  #9
Old 03-04-2010, 09:12 PM
SilveRanger01 SilveRanger01 is offline
Ford Truck Driver

Join Date: Dec 2009
Posts: 99
Default

Hmm, now I really want to do this to my truck as well. I'm sure I will when it gets a lil warmer If stiffer is all that happens, I can live with that, I drive semi's. Their suspension isn't always cushiony lol
__________________
2001 Ford Ranger XLT Stepside: Stock
Reply With Quote
  #10
Old 03-05-2010, 05:48 PM
878ranger878 878ranger878 is offline
Junior Ford Ranger Driver

Join Date: Jan 2010
Posts: 343
Default Re: tbar crank pics!!!

ya im dieing to do it too. if you do yours before i do tell me how it went and how everything was.
__________________
2003 FX4 Off Road- 4.0L V6
fav. mod- cab clearance lights

-torsion bars maxed-
Reply With Quote
  #11
Old 03-06-2010, 01:12 PM
2007BlackFX4 2007BlackFX4 is offline
Ford Ranger Driver

Join Date: Jan 2010
Posts: 837
Default Re: tbar crank pics!!!

heres mine

__________________
2007 Black FX4
Nitto Terra Grapplers - 285/75
Mickey Thompson Classic II's - 17"
Reply With Quote
  #12
Old 03-06-2010, 08:18 PM
878ranger878 878ranger878 is offline
Junior Ford Ranger Driver

Join Date: Jan 2010
Posts: 343
Default Re: tbar crank pics!!!

ok im so confused where is the tbar? what does it look like? any pic of it? and ive searched and searched for the answer?????????????????
__________________
2003 FX4 Off Road- 4.0L V6
fav. mod- cab clearance lights

-torsion bars maxed-
Reply With Quote
  #13
Old 03-06-2010, 08:51 PM
ranger101 ranger101 is offline
Ford Ranger Driver

Join Date: Dec 2009
Posts: 2,571
Default Re: tbar crank pics!!!

The circled item:
__________________
2002 XLT 4X4
Auto 4.0L SOHC
8.8 w/ 4.10 L/S

Mods: Xcal 2, K&N Drop-In, Line-X, DSG Heads/Corners, 6000k Hi/Low HID's, 6K HID Fogs, Foglight Mod, Throttle Cable Mod, 6.5" Digital Designs, Rockford P400.4, 2 Sundown SA-15's, MB Quart DSC 2000.1d, Cranked T-Bars, 285/75/R16 Nitto Terra Grapplers
Reply With Quote
  #14
Old 03-07-2010, 12:45 AM
2007BlackFX4 2007BlackFX4 is offline
Ford Ranger Driver

Join Date: Jan 2010
Posts: 837
Default Re: tbar crank pics!!!

lol yeah ^^ thats it. i have an even better picture of it from under my truck on my computer but i'm on my friends computer right now. i'll post it up later
__________________
2007 Black FX4
Nitto Terra Grapplers - 285/75
Mickey Thompson Classic II's - 17"
Reply With Quote
  #15
Old 03-07-2010, 09:23 PM
SilveRanger01 SilveRanger01 is offline
Ford Truck Driver

Join Date: Dec 2009
Posts: 99
Default Re: tbar crank pics!!!

Look under your truck for a crossmember that has two recessed holes. Thats where you can crank your T-bars at. I haven't done it, but mark it w/a marker or somethin so you know how many turns you've made, and measure wheel height from wheel to fender, and thats how far you've moved the torsion bars. Just watch your alignment, you might need one after you adjust them.
__________________
2001 Ford Ranger XLT Stepside: Stock
Reply With Quote
